24 Port GigE Lightning/Surge Protector, 70V Clamp, 10KA
- SKU: TP-ESP-1G-24RM
$1,337.43 $1,407.82
- Manufacturer: Tycon Power
- Data Sheet: Download
Product Information
Network Lightning/Surge Protector, 24 Port Rack Mount, 1Gbps Data Rate, LAN/POE 70V Clamp Voltage, 10KA Surge
Specifications
Specifications TP-ESP-1G-24RM
| Operating Voltage | Data 5V, POE < 56V |
| PoE Operating Current | 2.5A Max |
| Clamping Voltage Data | 10V, POE 120V (All 8 Pins) |
| Max Surge Discharge Current | 10KA (8/20us, 10 times with 3 mins interval) |
| Peak Pulse Current | 100A (10/1000us, 300 times with 3mins interval) |
| Protection Mode | Differential & Common Mode |
| Insulation Resistance | >1,000 MOhm |
| Shunt Capacitance | < 25 pF |
| Data Rate | 10/100/1000 Mbps (1Gbps) |
| Impulse Protected Voltage | <650V |
| Response Time | <5ns |
| Enhanced ESD | Protection +/-15KV (air), +/- 8KV (contact), Class C |
| Operating Temperature | -40 to +85°C (-40 to +185°F) |
| Storage Temperature | -40 to +85°C (-40 to +185°F) |
| Operating Humidity | 0% to 95% non condensing |
| Body Size (L x W x H) | 432 x 114 x 44.5mm (17” x 4.5” x 1.75”) |
| Weight 2Kg | (4.4lbs) |
| Rackmount Standard | 19” 1U |
| Connectors | RJ45 Shielded Jacks |
| Ethernet Cable Compatibility | CAT5, CAT5e, CAT6, CAT6a |
| Grounding Stud - Threaded | 4mm |
| Warranty | 3 Years |
