Voltage Converter 36-72VDC Input, 56VDC @ 4.46A 250W Regulated output, isolated
- SKU: TP-VRHP-4856-250
$392.92 $413.60
- Manufacturer: Tycon Power
- Data Sheet: Download
Product Information
Voltage Converter 36-72VDC Input, 56VDC @ 4.46A 250W Regulated output, isolated
Specifications
Specifications TP-VRHP-4856-250
| DC Input Voltage Range | +/- 36 to 72VDC |
| DC Voltage Output | 56VDC @ 4.46A |
| Maximum Power | 250W |
| Input / Output Isolation | Isolated |
| Efficiency | >85% |
| Load / Line Reg | 5% / 1% |
| Ripple / Noise | 2% / 5% |
| Isolation | 1500VDC Min. / 100M Ohms Min |
| Wire Gauge | 12AWG Max |
| Protections | Short Circuit, Overvoltage, Overload |
| Operating Temp | -22°F to 149°F (-30°C to +65°C) |
| Operating Humidity | 0 to 90% RH |
| Size | 5.9 x 7.4 x 1.7” (150x187x43.6mm) |
| Weight | 2.6lbs (1.2 kg) |
| Warranty | 3 Years |
