Cambium Networks cnMatrix TX1012-P-AC Intelligent Ethernet PoE Switch
- SKU: MXTX1012GxPA01
$1,422.51
- Manufacturer: Cambium Networks
- Data Sheet: Download
Product Information
Cambium Networks’ next generation switching platform offers a cloud managed, high performance, feature rich enterprise grade ethernet switching solution.
The cnMatrix series of fully managed switches delivers full Layer 2 and Layer 3 capabilities with enhanced access security. The cnMatrix series offers flexibility with SFP+ (10 Gbps) or SFP (1 Gbps) uplink ports. These switches come with a 3-Year Limited Lifetime Warranty
Product Features- 802.3af/at/bt - up to 90W
- 24V Passive PoE - up to 15W
- 54V Passive PoE - up to 90W
Specifications
| Throughput | 96Gbps |
| Forwarding Rate in Mpps (64 Byte Packets) | 120 |
| 10/100/1000 Mbps RJ45 Ports | 8 |
| 1 Gbps Fiber Ports (SFP) | 0 |
| 10 Gbps Fiber Ports (SFP+) | 4 |
| PoE+ Enabled Ports 802.3af/at/bt | 8 |
| Low Voltage Passive PoE (24V) | 4 |
| High Power 4 PPoE (up to 90W) | 2 |
| Serial Console | Yes |
| Rack Mount Kit | Yes, Optional |
| Internal Fans | 1 |
| Reset Button | Yes |
| MAC Address Table Size | 16K |
| Flash Storage | 128MB |
| DRAM | 512MB |
| VLANs | 4K |
| QinQ | Yes |
| LACP/Trunking | 8 LAGs/8 links per LAG |
