MikroTik RB1100x4 1U Rackmount Router with 13x GbE
- SKU: RB1100x4
$451.75 $465.73
Product Information
The MikroTik RouterBOARD 1100x4 includes a powerful 1U rackmount router with 13x Gigabit Ethernet ports. This board is powered by an Annapurna Alpine AL21400 CPU with four Cortex A15 cores, clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbit. The device supports IPsec hardware acceleration (up to 2.2Gbps with AES128).
The 1100x4 comes with a 1U rackmount case, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support).
Product Features- 1U rackmount router
- 13x GbE ports
- Annapurna Alpine AL21400 CPU with four Cortex A15 cores
- Maximum throughput of 7.5Gbit
- RS232 serial port
- Dual redundant power supplies
- 1U rackmount case
- SATA cables
- K-10 R2 screw kit
- Rackmount ears
- 2x IEC cord (US cord)
- M.2 SSD 60GB
Specifications
Specifications RB1100AHx4
| Architecture | ARM 32bit |
| CPU | AL21400, 4 cores, 1.4GHz |
| Size of RAM | 1GB |
| Storage type | NAND |
| Storage size | 128MB |
| 10/100/1000 Ethernet ports | 13 |
| Ethernet bypass | Ethernet 11/12 |
| Power jack | 2x IEC. 100V - 240V |
| DC telecom power | 20V - 57V (-48V supported) |
| PoE input | Passive, 802.3at. 20 - 57V |
| Redundant power supply | Yes |
| Voltage monitor | Yes |
| PCB temperature monitor | Yes |
| Current monitor | Yes |
| Dimensions | 444 x 148 x 47 mm |
| Operating system | RouterOS, level 6 license |
| Max Power consumption | 25W |
| microSD | 1 |
| SATA | 2x 2.5 inch SATA 3 |
| M.2 slots | 2x SATA 3 compatible (supports 2242, 2260 and 2280 sizes, M-key) |
| Serial port | RS232 |
| Beeper | Yes |
