MikroTik Cloud Router Switch 48x 1G RJ45 Ports 800W
- SKU: CRS354-48P-4S+2Q+RM
Product Information
Introducing the MikroTik CRS354-48P-4S+2Q+RM, your ultimate 48-Port solution with integrated PoE. If you're seeking a singular switch to elevate your network infrastructure and power essential devices, look no further! Engineered for versatility and performance, the CRS354-48P-4S+2Q+RM excels in managing networks across diverse and challenging environments.
Featuring 48x 1G RJ45 ports and 4x 10G SFP+ ports, alongside 2x 40G QSFP+ ports for high-speed fiber connections and device linking, this robust switch offers unparalleled connectivity options. Each Ethernet port supports multiple power output choices, including Passive PoE and 802.3af/at (Type 1 and Type 2) with auto-sensing capabilities, ensuring effortless integration into any network scale. Equipped with a robust 750W power supply, the CRS354-48P-4S+2Q+RM handles demanding workloads with ease, complemented by a dedicated bracket for simplified cable management.
The CRS354-48P-4S+2Q+RM combines exceptional functionality with the most competitive pricing in its class, making it an ideal addition to any professional setup. With a non-blocking throughput of 168Gbps, a switching capacity of 336Gbps, and a forwarding rate of 235Mpps, it sets a new standard in network performance and reliability.
Product Features- 48 Gigabit Ethernet ports supporting 802.3af/at PoE
- Four 10G SFP+ ports
- Two 40G QSFP+ ports
- 1x RJ45 console port (set at 115200bits/s, 8 data bits, 1 stop bit no parity)
- 1x 10/100Mbit Ethernet port for management access
- Four cooling fans with automatic speed control
- 2x IEC Cords (U.S. Plug)
- K-48 Screw Kit
- Rackmount Rear Support Ears
- Rackmount Ears
- Cable Management Brackets
Specifications
Specifications CRS354-48P-4S+2Q+RM
| CPU | QCA9531, 650 MHz |
| Size of RAM | 64 MB |
| Storage | 16 MB flash |
| Number of 100 Mbps Ethernet ports | 1 |
| Number of 1 GbE Ethernet ports | 48 |
| 10G SFP+ ports | 4 |
| 40G QSFP+ ports | 2 |
| Operating system | RouterOS (License level 5) |
| Supported input voltage | AC power supply 100 - 240 V |
| Serial port | RJ45 |
| Dimensions | 443 x 382 x 44 mm |
| Operating temperature | -20°C to +60°C |
| Powering | |
| PoE-out | IEEE 802.3at/af and 26 or 53 V Passive PoE |
| PoE-out ports | Ether1 - Ether48 |
| PoE-out max per port (low voltage 26 V) | 26 W |
| PoE-out max per port (high voltage 53 V) | 30 W |
| Max total out (low voltage 26 V) | 27 A |
| Max total out (high voltage 53 V) | 13.2 A |
| Max power consumption | 800 W |
| Max power consumption without attachments | 85 W |
